Panda PVK-U Fixed Generators

PANDA xControl

The original Panda concept - small, lightweight and quiet.

The original 3000rpm concept with Panda's latest digital based Xcontrol range from 6.8 - 75kW.

Using the reliable multi-cylinder Kubota diesel engine for sets up to 30kVA with reputable engine options for sets above this size and the Fischer Panda water-cooled asynchronous alternator, controlled by Fischer Panda's patented VCS (voltage control system) system.

Three alternator options available, HP1 - 1 phase, HP3 - 3 phase or DVS - mixed 1 phase and 3 phase up to the capacity of the system.

Options also available in 120V / 60Hz




Products

Panda 15000 PVK-U

PANDA 8000x PVK-U

stage 5 v1

  • 230V AC output
  • Nominal Output 6.8kW (8.0kVA)
  • Weight -  279kg
  • Dimensions (mm) L870 x W523 x H580

FIND OUT MORE

Panda 15000 PVK-U

PANDA 10000x PVK-U

stage 5 v1

  • 230V AC output
  • Nominal Output 8kW (9.4kVA)
  • Weight -  290kg
  • Dimensions (mm) L910 x W522 x H620

FIND OUT MORE

Panda 15000 PVK-U

PANDA 15000x PVK-U

stage 5 v1

  • 230V AC output
  • Nominal Output 12.7kW (15kVA)
  • Weight -  365kg
  • Dimensions (mm) L1000 x W530 x H630

FIND OUT MORE

Panda 15000 PVK-U

PANDA 18x PVK-U

stage 5 v1

  • 230V AC output
  • Nominal Output 15.3kW (18kVA)
  • Weight -  440kg
  • Dimensions (mm) L1100 x W560 x H680

FIND OUT MORE




Other models include:-

Panda 12000 PVK-U | Panda 24 PVK-U | Panda 30 PVK-U

Overview Brochure

Contact us if you require any further sales or technical advice.
