Panda PVK-UK Fixed Generators

PANDA xControl

The original Panda concept - small, lightweight and quiet.

The original 3000rpm concept with Panda's latest digital based Xcontrol range from 6.8 - 75kW.

Using the reliable multi-cylinder Kubota diesel engine for sets up to 30kVA with reputable engine options for sets above this size and the Fischer Panda water-cooled asynchronous alternator, controlled by Fischer Panda's patented VCS (voltage control system) system.

Three alternator options available, HP1 - 1 phase, HP3 - 3 phase or DVS - mixed 1 phase and 3 phase up to the capacity of the system.

Options also available in 120V / 60Hz




Products

10000i pvk-uk p1

PANDA 8000x PVK-UK

stage 5 v1

  • 230V AC output
  • Nominal Output 6.8kW (8.0kVA)
  • Weight -  332kg
  • Dimensions (mm) L1330 x W522 x H620

FIND OUT MORE

10000i pvk-uk p1

PANDA 10000x PVK-UK

stage 5 v1

  • 230V AC output
  • Nominal Output 8kW (9.4kVA)
  • Weight -  340kg
  • Dimensions (mm) L1516 x W522 x H620

FIND OUT MORE

pvk-uk 25i p2 P1480844

PANDA 15000x PVK-UK

stage 5 v1

  • 230V AC output
  • Nominal Output 12.7kW (15kVA)
  • Weight -  430kg
  • Dimensions (mm) L1606 x W522 x H630

FIND OUT MORE

pvk-uk 25i p2 P1480844

PANDA 18x PVK-UK

stage 5 v1

  • 230V AC output
  • Nominal Output 15.3kW (18kVA)
  • Weight -  544kg
  • Dimensions (mm) L1736 x W560 x H680

FIND OUT MORE





Other models include:-

Contact us if you require any further sales or technical advice.


Larger output models available on request

Overview Brochure

Contact us if you require any further sales or technical advice.
